Our Rigs : RIG 211
DRAWWORKS
Walker Neer Apache 250-40
Capacity: 250,000 lbs
Rated Power: 400 HP
DERRICK & SUBSTRUCTURE
Walker Neer Three Axle Trailer
Floor Height: 6’, Clear Working Height: 4‘
Rotary Capacity: 250,000 lbs
No Setback
PUMPS
Ideco MM550, 550 HP, 15” Stroke
Caterpillar C-15 Mud Pump Drive
MUD SYSTEM
One Tank System: 550 bbls
No Shakers, Desilter, Desander, Vacuum Desaser, Trip Tank, or Mud Gas Separator
BOP / WELL CONTROL
Annular: 9“ x 3000 psi
MAST
Walker Neer Single – 60’
Static Hook Load: 250,000 lbs
4 Lines, 1” Drill Line Size
No Setback Racking Capacity
